Door Frame Calculator
Lining timber lengths, architrave LM, threshold, and fixings - calculated per door with standard size presets.
Should match wall thickness + plaster both sides. Typical: 95 - 133 mm for 100 mm stud, 145 mm for 140 mm stud.
Typically 25 mm for softwood, 18 - 22 mm for MDF.
Architrave both sides of every door. 2 verticals + 1 head per side.
Face width: common 57, 69, 90 mm.
Typically needed for external doors and room changes in floor type.
Stop bead nailed to lining - 2 verticals + 1 head per opening.
Doors
Job Costing (optional)
Or use kit price per door below.
Pro featurePopulate cost fields with current UK market prices. Sign in or upgrade to access.
Results
Doors
-
openings
Lining to buy
-
linear metres
Architrave to buy
-
linear metres
Stop bead to buy
-
linear metres
Material List
Door Breakdown
| Door / location | Opening (WxH) | Lining LM | Arch. LM | Stop LM | Threshold |
|---|
🚫 Estimate waste & skip size for this project →
Doing this as a homeowner?
Who do you actually need to hire for this?
Not sure what some of these terms mean?
Browse all →
Frequently Asked Questions
What is the difference between a door lining and a door frame?
Door lining: three-sided timber frame lining a stud partition opening - door is hung directly onto the lining. Door frame: more substantial frame for masonry openings, includes a doorstop rebate the door closes against. Linings are used in internal stud partitions; frames in external or masonry openings.
What sizes do door linings come in?
Standard lining depths: 95 mm, 108 mm, 133 mm, or 145 mm to suit common wall thicknesses. Sold as sets (head + two jambs) pre-cut to the door opening size. The lining opening should be door size plus approximately 10 mm in each direction. Always specify the wall depth when ordering as linings are not universal.
How much architrave do I need per door?
For a standard single door (762-838 mm wide x 1981 mm high): approximately 5.2 m per side (two 2.1 m legs + one 1.0 m head). Both sides: approximately 10.4 m per door. Architrave is typically sold in 2.1 m or 4.2 m lengths. Remember to order for both faces of every doorway.
What is the standard door height and width in the UK?
Most common internal doors: 762 x 1981 mm (2'6" x 6'6") and 838 x 1981 mm (2'9" x 6'6"). Bathroom/WC doors: often 686 x 1981 mm. Modern metric sizes: 826 x 2040 mm and 726 x 2040 mm. Under Approved Document M (accessibility), minimum clear opening width for wheelchair users is 775 mm, requiring at least an 838 mm door.
What clearance should I leave around a door in its lining?
Sides and top: 2-3 mm clearance between door leaf and lining. Bottom: 6-10 mm over finished floor for air movement; 12-15 mm if a carpet threshold is needed. The lining opening should be door size plus 10 mm width and 10 mm height for fitting clearance, plus lining thickness on each side.
Do I need fire doors for internal doorways?
Under Approved Document B: fire doors required between an integral garage and the house (FD30 minimum); on doors onto a protected stairway in a 3-storey+ home. Converted flats and HMOs: more extensive requirements. Fire doors must have intumescent strips, cold smoke seals, self-closing devices, and certified fire door hardware.
